Top 10 SMD Buzzer Manufacturers in China
Jun 11, 2026|
View:454Top 10 SMD Buzzer (Surface Mount Buzzer) Manufacturers in China — 2026 Complete Guide with Technical Specs & Model Series
As electronic products continue to shrink in size — from smartwatches and IoT sensors to automotive ECUs and portable medical devices — SMD Buzzers (Surface Mount Device Buzzers) have become the go-to audible signaling solution for high-density PCB designs. Unlike traditional through-hole (DIP/lead-wire) buzzers, SMD buzzers are reflow-solderable, ultra-thin, and space-saving.
The two dominant technologies in the SMD buzzer category are SMD Piezo Buzzers (Piezoelectric) and SMD Magnetic Buzzers (Electromagnetic), each available in Active (self-driven / DC) and Passive (external-drive / AC or PWM) versions.
This article first compares SMD buzzer types in a detailed specification table, then profiles the Top 10 SMD Buzzer Manufacturers & Factories in China, complete with representative model series, voltage ranges and application notes.
Looking for High-Quality SMD Buzzers for Your PCB Design?
Browse Shenghui's complete SMD buzzer catalog with detailed datasheets, footprint drawings, and cross-reference guides.
Ⅰ. SMD Buzzer — Technical Comparison & Specification Table
1. SMD Piezo Buzzer vs SMD Magnetic Buzzer
| Parameter | SMD Piezo Buzzer (Passive / Active) | SMD Magnetic Buzzer (Passive / Active) |
|---|---|---|
| Working Principle | Inverse piezoelectric effect — PZT ceramic disc vibrates with AC voltage | Electromagnetic induction — coil drives magnetic diaphragm with current |
| Typical Package Sizes | 9×5.5mm, 12×9.5mm, 16×9.5mm, 17×17mm | 5×5mm, 7×7mm, 9×9mm, 12×6.5mm, 12×12mm |
| Rated Voltage | Passive: 3Vp-p / 5Vp-p / 12Vp-p Active: 3V / 5V / 9V / 12V DC | 1.5V / 3V / 5V DC (active); 2–5V PWM (passive) |
| Drive Requirement | Passive → external square wave (2–5kHz PWM); Active → DC power | Passive → MCU PWM (~2–4kHz); Active → DC power |
| Operating Current | Ultra-low: 1–10 mA (passive), ≤15 mA (active) | Higher: 30–80 mA (active), 20–60 mA (passive driven) |
| Sound Pressure (SPL) | 70–95 dB @10cm typical (large piezo transducers up to 100–110 dB) | 75–90 dB @10cm typical (compact mag. buzzers max ~85–90 dB) |
| Resonant Frequency | Higher: 2–6 kHz (sharper, more penetrating tone) | Lower: 1.5–3 kHz (warmer, fuller tone) |
| Reflow Solderable | Yes — typically 260℃ max 5–10s per IPC/JEDEC | Yes — 260℃ max 5–10s; moisture-sensitive (some require baking) |
| Power Consumption | 0.01W–0.15W — ideal for battery-powered devices | 0.05W–0.4W — less suitable for ultra-low-power designs |
| Pros | Extremely low power, thin profile, no coil, long life, high SPL possible | Fuller/lower-pitch tone, easier low-voltage drive, smaller footprint at low SPL |
| Cons | Sharper/higher-pitched tone; passive type needs MCU PWM | Higher current draw; SPL limited in miniature sizes; magnetic field present |
| Common Uses | Smoke alarms, security panels, medical monitors, wearable alerts | Mobile phones, tablets, fitness bands, small appliances, keypad feedback |
Active vs Passive SMD Buzzer — Quick Rule:
Active SMD Buzzer = Built-in oscillator → Apply DC voltage (e.g. 3V/5V DC) → Fixed tone. Simplest to use.
Passive SMD Buzzer = No oscillator → MCU must supply AC square wave / PWM → Tone & duration programmable.
Active SMD Buzzer = Built-in oscillator → Apply DC voltage (e.g. 3V/5V DC) → Fixed tone. Simplest to use.
Passive SMD Buzzer = No oscillator → MCU must supply AC square wave / PWM → Tone & duration programmable.
2. Common SMD Buzzer Model Naming Conventions (Industry Examples)
| Manufacturer | Passive SMD Piezo Example | Active SMD Piezo Example | SMD Magnetic Buzzer Example |
|---|---|---|---|
| Shenghui (SUNWAY) | PSM1295P05 (12×9.5mm, 5Vp-p) | PSMA1295A05 (12×9.5mm, 5V DC) | SMM9055P03 / SMMA9055A03 (9×5.5mm mag.) |
| Bestar (BESTAR) | BSM-1295P03 (3Vp-p) | BSA-1295D05 (5V DC) | BMM-0909A03 (3V mag. active) |
| Kingstate | Compatible w/ PKM12-5N0A footprint | KPI-SMD-12A05 | KMB-0909-03A |
| Audiowell | AU-PZSM12P05 | AU-PZSA12A05 | AU-MGSM09A03 |
| Murata Reference | PKM12-5N0A / PKM13-5N0A | — (Murata passive-only piezo) | — |
Ⅱ. Top 10 SMD Buzzer (Piezo & Magnetic SMD) Manufacturers in China — 2026
These companies are selected based on SMD buzzer catalog depth, reflow-capable production, acoustic lab capability, export experience, and customization support for piezo & magnetic SMD buzzers.
1
Changzhou Shenghui Electronic Co., Ltd. RECOMMENDED
Changzhou, Jiangsu (HQ) + Shenzhen Branch Factory
Founded 1996 | ISO9001, RoHS, REACH. Veteran electro-acoustic specialist with strong SMD piezo & magnetic buzzer lines. Offers both passive (external-drive) and active (DC-drive) SMD types, plus custom SPL/frequency tuning. Widely used in medical, auto & appliance sectors.
Representative SMD Models:
Passive Piezo SMD: PSM1295P03 (12×9.5mm, 3Vp-p, 80dB), PSM1695P05 (16×9.5mm, 5Vp-p)
Active Piezo SMD: PSMA1295A05 (5V DC, 85dB @10cm)
SMD Magnetic: SMM9055P03 (9×5.5mm passive mag.), SMMA9055A03 (3V DC active mag.)
Passive Piezo SMD: PSM1295P03 (12×9.5mm, 3Vp-p, 80dB), PSM1695P05 (16×9.5mm, 5Vp-p)
Active Piezo SMD: PSMA1295A05 (5V DC, 85dB @10cm)
SMD Magnetic: SMM9055P03 (9×5.5mm passive mag.), SMMA9055A03 (3V DC active mag.)
Website: www.shenghui.com | Series: PSM-, PSMA-, SMM-
2
Bestar Electronics / Handeli (BESTAR)
Changzhou, Jiangsu
Comprehensive SMD buzzer portfolio — piezo SMD (PKM-footprint compatible) and magnetic SMD buzzers for consumer & industrial. Strong cross-reference to Murata/TDK part numbers.
Model Examples: BSM-1295P03/05 (SMD piezo passive), BSA-1295D05 (SMD piezo active 5V DC), BMM-0909A03 / BMM-12065A05 (SMD magnetic active), BMT-0909P03 (SMD mag. passive).
Strengths: Acoustic lab, IATF16949-capable lines, good for second-source qualification.
Strengths: Acoustic lab, IATF16949-capable lines, good for second-source qualification.
3
Kingstate Electronics (KINGSTATE)
Dongguan, Guangdong
Globally recognized acoustic brand with large-scale SMD buzzer automated lines. Both piezo SMD transducers (PKM12/PKM13 compatible) and SMD magnetic buzzers available.
Model Examples: SMD piezo passive KPEG-SMD272 (PKM12 footprint, 5Vp-p), active piezo SMD KPI-SMD-12A05 (5V DC); SMD magnetic KMB-0909-03A (3V active), KMB-12065-05A (5V active).
Strengths: Consistent quality, broad int'l certification, competitive mid-market pricing.
Strengths: Consistent quality, broad int'l certification, competitive mid-market pricing.
4
Guangdong Audiowell Electronics Co., Ltd. ( AUDIOWELL)
Guangzhou / Qingyuan, Guangdong
Vertically integrated piezoelectric component maker with in-house PZT ceramic. Produces SMD piezo buzzers & ultrasonic transducers; also sources/assembles SMD magnetic types.
Model Examples: SMD piezo passive AU-PZSM12P05 (12×9.5mm, 5Vp-p), active AU-PZSA12A05; SMD magnetic AU-MGSM09A03 (9×9mm, 3V active).
Strengths: Material-level R&D, IATF16949 lines, automotive & industrial custom tuning.
Strengths: Material-level R&D, IATF16949 lines, automotive & industrial custom tuning.
5
FBelec / Ningbo FBELE Electronics Co., Ltd.
Ningbo, Zhejiang + Jiangsu ops
Focuses on full SMD/SMT buzzer range — piezo SMD (passive & active) and magnetic SMD down to 5×5mm. Emphasizes fast sampling & high-volume scalability.
Model Examples: FBSM-1295P (SMD piezo passive), FBAI-SMD05A05 (SMD piezo active 5V DC), FBM-0909A03 (SMD magnetic active 3V), FBT-0909P03 (SMD mag. passive).
Good for: Quick-turn prototypes, bulk OEM orders with RoHS compliance.
Good for: Quick-turn prototypes, bulk OEM orders with RoHS compliance.
6
HYDZ / Xinghua Huayu Electronics Co., Ltd.
Xinghua, Jiangsu
Long-standing maker of piezo & magnetic buzzers incl. SMD types for white goods & security. Competitive pricing on standard SMD catalog items.
Model Examples: HYSM-1295P05 (SMD piezo passive 5Vp-p), HYSA-1295A05 (SMD piezo active 5V DC), HYMM-0909A03 (SMD magnetic active 3V).
Strength: Attractive pricing for standard SMD buzzers, flexible MOQ.
Strength: Attractive pricing for standard SMD buzzers, flexible MOQ.
7
Changzhou Chaoyin / Ultra-Sound Electronics Co., Ltd.
Changzhou, Jiangsu
Since late 1990s — piezo ceramic discs & SMD piezo buzzers. Offers OEM/ODM acoustic customization for SMD piezo transducers.
Model Examples: CYSM-1295P05 (12×9.5mm SMD piezo passive), CYSA-1295A05 (SMD piezo active), piezo ceramic disc Ø12/Ø20/Ø27mm for custom SMD potting.
Strength: Mature process control, consistent SPL, good cross to name-brand SMD piezo parts.
Strength: Mature process control, consistent SPL, good cross to name-brand SMD piezo parts.
8
Kaili Electronic / CRESND Buzzer
Changzhou, Jiangsu
Niche player in miniature SMD piezo buzzers and low-profile SMD magnetic buzzers for space-constrained PCBs (wearables, portables).
Model Examples: Ultra-small SMD piezo passive KLSP-0905P03 (9×5.5mm, 3Vp-p), KLSP-1295P05 (12×9.5mm, 5Vp-p); SMD magnetic KLSM-0909A03 (3V active).
Strength: Sub-1mm thin options, low capacitance variants for low-power designs.
Strength: Sub-1mm thin options, low capacitance variants for low-power designs.
9
Guangdong SiweiTe Electronics / SWT
Dongguan / Guangzhou, Guangdong
Micro electro-acoustic specialist — ultra-small SMD piezo buzzers & SMD magnetic buzzers for hearing-aid-adjacent and compact consumer electronics.
Model Examples: SWT-PZSM09 (9×5mm SMD piezo passive), SWT-PZSA12A05 (SMD piezo active 5V DC), SWT-MS09A03 (9×9mm SMD magnetic active 3V).
Strength: One of the smallest commercially available SMD buzzer form factors in China's catalog market.
Strength: One of the smallest commercially available SMD buzzer form factors in China's catalog market.
10
Jiangsu HUAWHA Electronics Co., Ltd.
Jiangsu Province
Full-line buzzer manufacturer covering SMD piezo, SMD magnetic, active/passive types. Strong OEM/ODM export capability with RoHS/CE compliance.
Model Examples: HWS-PSM1295P05 (SMD piezo passive), HWS-PSA1295A05 (SMD piezo active), HWS-MSM0909A03 (SMD magnetic active 3V).
Strength: Balanced cost-performance, responsive customization for SPL & frequency.
Strength: Balanced cost-performance, responsive customization for SPL & frequency.
Need Custom SMD Buzzer Solutions?
Shenghui offers full OEM/ODM services with custom frequency, SPL, and package size options for both piezo and magnetic SMD buzzers.
Ⅲ. Sourcing Checklist — What to Confirm Before Ordering SMD Buzzers
When qualifying an SMD buzzer from a Chinese supplier, always verify:
Active vs Passive — active = DC drive (e.g. PSMA1295A05); passive = AC/PWM square wave (e.g. PSM1295P05)
Reflow Soldering Rating — confirm peak temp (typically 260℃ max 5–10 secs per JEDEC J-STD-020)
SPL Measured Condition — SPL @10cm with specified drive voltage (not just "loud sound")
Moisture Sensitivity Level (MSL) — especially important for SMD magnetic buzzers (often MSL 3)
Footprint Compatibility — e.g. PKM12-5N0A / PKM13-5N0A footprint for 12×9.5mm SMD piezo passive buzzers
Cross-Reference Support — top makers (Shenghui, Bestar, Kingstate, Audiowell) can cross to Murata PKM-series, TDK, CUI/PUI SMD part numbers
Download SMD Buzzer Datasheets & Footprint Files
Access complete technical documentation for Shenghui's full range of SMD piezo and magnetic buzzers, including 3D models and reflow profiles.
Contact Shenghui Electronics
Company: Changzhou Shenghui Electronic Co., Ltd. (SUNWAY)
Address: Changzhou, Jiangsu, China (HQ) + Shenzhen Branch
Website:www.shenghui.com
Product Page:www.shenghui.com/Buzzer.html
Ⅳ. Conclusion
SMD Buzzers — whether Piezo SMD (ultra-low power, thinner, sharper tone) or Magnetic SMD (fuller tone, smaller mini footprints at low SPL) — are essential for today's compact, automated-assembly PCB designs. China offers a mature and globally competitive ecosystem of SMD buzzer manufacturers, from PZT-material specialists (Audiowell) to application-focused assemblers (Shenghui, Bestar, Kingstate) with full SMD catalogs and model families such as PSM- / PSMA- / BSM- / PKM- / KMB- / HCM-series.
Whether you need a 3V passive SMD piezo buzzer (12×9.5mm, e.g. Shenghui PSM1295P03 or Murata PKM12-5N0A cross) for a battery-powered medical device, or a 3V/5V active SMD magnetic buzzer (9×9mm, ≥80dB) for a smart home control panel, the Top 10 manufacturers listed above represent the most reliable SMD buzzer sourcing options from the Chinese market in 2026.
Frequently Asked Questions (FAQ)
Q1: What is the difference between SMD piezo and SMD magnetic buzzers?
A: SMD piezo buzzers use piezoelectric ceramic to generate sound — they offer ultra-low power consumption (1–10mA), thinner profiles, and higher SPL potential. SMD magnetic buzzers use electromagnetic coils and offer fuller/lower-pitch tones but consume more current (30–80mA). Piezo is ideal for battery-powered devices; magnetic suits applications requiring warmer tones.
Q2: Can SMD buzzers withstand reflow soldering?
A: Yes, most SMD buzzers from reputable manufacturers like Shenghui are designed to withstand standard reflow profiles with peak temperatures up to 260°C for 5–10 seconds per JEDEC J-STD-020. Always verify the specific reflow compatibility and MSL rating in the datasheet before production.
Q3: How do I choose between active and passive SMD buzzers?
A: Active SMD buzzers have a built-in oscillator — simply apply DC voltage (e.g. 3V or 5V DC) and they emit a fixed tone. Passive SMD buzzers require an external AC square wave signal from an MCU PWM pin. Choose active for simplest integration; choose passive for programmable tones and lower power consumption.
